RELIABLE AND POWERFUL JASPI FIL ELECTRIC BOILERS FROM 31 TO 1800kW

3-Phase power and full control

All Jaspi FIL boilers are made to to order. Every component is tested several times throughout the manufacturing to ensure the ultimate reliability, efficiency and the safe use of the boiler. Industrial grade casing and efficient insulation will retain the system performance throughout it's extended service life.

High power also needs reliable and flexible control. Jaspi FIL boilers include an intelligent power control which will adjust the boiler power according to the heat demand and the total electricity use in the property. Therefore it is safe to use any additional electrical devices like cookers, heaters or hot water cylinders without a danger of the elactrical system overload.

All Jaspi FIL boilers are built for 3-phase electrical connection. They are designed for easy fitting and minimum servicing with industrial quality reliability and long service life.

jaspi_electric_boilers

JASPI FIL-B Boilers 31 - 105kW

FIL-B series boilers are designed to be connected directly to the radiator / underfloor heating system and can also be equipped with an indirect coil for domestic hot water.
They have a proportional mixing valve which can be fitted with a flow temperature controller to achieve a constant temperature controlled flow (often used with underfloor heating or low surface temperature radiators) or for example room or weather compensating controller.

Jaspi FIL-B boilers come in sizes; 31 and 42kW with a 240L water capacity and 52, 70, 84 and 105kW with 750L internal water capacity.

Large internal water volume highly increases boiler's efficiency and allows the step-power control due to the higher than normal heat retention.
This means that the boiler does not need to fire up with all it's capacity when the heat is used but can start with less power and then increase it if and when needed.

7-stage power control with power supply transformers and an automatic safety master switch are fitted as standard.
The size (flow rate) of a domestic hot water coil is normally 35 or 50L / minute, depending on the power of the boiler.

JASPI FIL-SPL 31 - 300kW

FIL-SPL are powerful and economical electric boilers without a domestic hot water coil.
These boilers are a perfect partner for accumulators, district heating systems and are often used to provide automatic back-up for oil/gas and biomass boilers.

Jaspi FIL-SPL have a 7 or 15-stage power control which adjusts the boiler power according to the heat load and the available incoming electricity supply.
Automatic safety master switch will protect the boiler in case of a overheating or other abnormality.

JASPI FIL-SPL 400 - 1800kW

These are the largest and the most powerful FIL Boilers for large heating systems, public buildings and industrial processes.

Intelligent controls and industrial grade robust construction makes these FIL boilers a perfect choice anywhere where continuous and reliable heat supply is important.

As the other FIL-SPL boilers, these units have a 7, 15 or 30-stage power control which adjusts the boiler power according to the heat load and the available incoming electricity supply.
Automatic safety master switch will protect the boiler in case of a overheating or other abnormality.

FIL-SPL boilers come in different size cabinets depending on the power / capacity, please refer to the table below.

Built to order

All Jaspi FIL boilers are built to order with delivery times from two to six weeks. Please contact us for more information and pricing details.

JASPI FIL ELECTRIC BOILER RANGE


  •
  • Power range kW
  • Water capacity
  • Size HxWxD mm
  • Weight kgs
  • DHW coil (optional)
  • 7-Stage Power Control
  • Connection size
  • Anti-Boiling system
  • Expansion vessel (opt)
  • Max. Pressure / Temp.
  • FIL-B (240)
  • 31 - 42
  • 240L
  • 1400 x 600 x 815
  • 150
  • 1 x 35L / Minute
  • Yes
  • DN25 (1")
  • -
  • 25L
  • 1.5bar / 100°C
  • FIL-B (750)
  • 52 - 105
  • 750L
  • 1900 x 900 x 1100
  • 330
  • 1 x 50L / Minute
  • Yes
  • DN32 (1¼")
  • -
  • 80L
  • 1.5bar / 100°C
  • FIL-SPL (A)
  • 31 - 105
  • 85L
  • 1560 x 445 x 665
  • 170
  • N/A
  • Yes
  • DN50 (2")
  • -
  • 15L
  • 10bar / 100°C
  • FIL-SPL (B)
  • 112 - 300
  • 220L
  • 1900 x 700 x 855
  • 320
  • N/A
  • Yes
  • DN65 - 80
  • Yes (over 120kW)
  • 25L
  • 10bar / 100°C
  • FIL-SPL (C, D, E)
  • 400-1800
  • 480 - 1000L
  • See brochure
  • 650 - 1500
  • N/A
  • Yes
  • DN80 - 125
  • Yes
  • 50-115L
  • 10bar / 100°C
